Burners 1 Triple Ring, 1 Rapid, 1 Semi Rapid
Rated Power 3.8kW, 2.5kW, 1.5kW(LPG)
Pan Support Cast Iron
Dripper Enamel
Ignition Type Pulse igniter(AC 220V)
Fire Failure Devie With FFD
Knob Metal
Options DC 1.5V, SS Dripper
Dimension 800x380x145(mm)
Cutting Size 705x325(mm)
Packing Size 905x445x200(mm)
Weight 14.5/15.5(kg)
20'/40'/40' HQ 380/740/870pcs
Catalog
Detail

                        INSTALLATION GUIDE


                        HOB

                        GF380E001

开孔图 265x475.png
