Burners 2 Triple Ring, 2 Semi Rapid
Rated Power 3.5kW, 3.5kW, 1.75kW, 1.75kW(LPG)
Pan Support Cast Iron
Dripper Enamel
Ignition Type Pulse igniter(AC 220V)
Fire Failure Devie With FFD
Knob Metal
Options DC 1.5V, SS Dripper
Dimension 1000x380x135(mm)
Cutting Size 865x325(mm)
Packing Size 1065x445x200(mm)
Weight 14.5/17.0(kg)
20'/40'/40' HQ 320/640/740pcs
Catalog
Parameters
Burners
2 Triple Ring, 2 Semi Rapid
Rated Power
3.5kW, 3.5kW, 1.75kW, 1.75kW(LPG)
Pan Support
Cast Iron
Dripper
Enamel
Ignition Type
Pulse igniter(AC 220V)
Fire Failure Devie
With FFD
Knob
Metal
Options
DC 1.5V, SS Dripper
Dimension
1000x380x135(mm)
Cutting Size
865x325(mm)
Packing Size
1065x445x200(mm)
Weight
14.5/17.0(kg)
20'/40'/40' HQ
320/640/740pcs
I know
Detail

                        INSTALLATION GUIDE


                        HOB

                        GF410C002
